Flat Panel Speakers

2030-p1
2030-p2
2030-p3
2030-p4
2030-p6
2030-zumen
size-comparison

FPS2030M3P1R transducer

US$684.73

Neodymium magnet 600pcs inside!!

The largest MCMA transducer. Recent years, it has been using as Large Digital Visions loudspeaker for outdoor use. Speakers made with this transducer have been adopted as almost all of the large advertising vision display sound in Tokyo. Its clear plane wave sound and thin design has got high praise from its users.



Note: This product’s backorder takes a few months for manufacturing.

50 in stock (also available on backorder)

Product Description

It allows to handle up to 125 watts (250 watts max), and design a planar wave pattern from 90 to 10,000 Hz.

FPS flat speaker output power is the all factors that of the proportions, its size of the area.

  • Unique MCMA construction places the voice coil on the diaphragm for immediate transient response
  • Extremely thin design with full range output from 90 to 10,000 Hz
  • Perfect for outdoor using
  • Planar wave launch for focused output that travels further than a radial wave launch of a conventional speaker
  • Great for use as a wide-band or midrange speaker



Applications

Public announcement system at railroad stations and large advertising systems, amusement park machines, concert halls, lecture halls etc.



Specifications

Product Name FPS2030M3P1R
Type MCMA (Multi Cell Microtransducer Array) Flat Speaker unit
Rated Input 125W constanly (Max.250W moment peak)
Rated Impedance
Frequency Characteristics 90Hz-10kHz
SPL 89dB±3dB
Dimensions W264.4mm x H364.4mm x D14.2mm
Weight 2,200g
Cold/Heat Resistance -30℃ to 70℃
Humidity Resistance 40℃, 90-95%
RoHS Comply with RoHS all of parts



technicaldata-fps2030m3p1r

Additional Information

Weight 2.5 kg

Country of origin

This product made in Japan.
